冲裁次数 Punches frequency |
10∽35（次/分） 10-35times/min |
|
生产能力 Production capacity |
1200∽4200（一冲两版）（版/小时） 1200-4200plates/hour( two plates one time) |
|
最大成型面积及深度 Max. forming area and depth |
130×100(标准深度≤15mm）最大深度26mm 130x100(standard thickness≤15mm) Max. depth 26mm |
|
行程范围 Stroke range |
50∽120mm（可按用户要求设计） 50-120mm( can be designed as per user’s required) |
|
标准版块 Standard plate size |
80×57mm（可按用户要求设计） 80x57mm ( can be designed as per user’s required) |
|
洁净压缩空气 Clean compressed air |
0.4∽0.6Mpa |
|
耗气量 Air compressed
capacity |
（空压机）≥0.3m3/min |
|
电源总功率 Total power supply |
380V 50HZ 3.8kw |
|
主电机功率 Main power |
1.5KW |
|
PVC硬片 PVC hard film |
（0.15∽0.5）×150mm |
|
PTP铝箔 PTP Aluminum film |
（0.02∽0.035）×150mm |
|
透析纸 Dialysis paper |
（0.02∽0.035）×150mm |
|
模具冷却 Mould cooling |
自来水或循环水 Tap water or recycling water |
|
外形尺寸 Overall dimension |
2315×635×1405mm（L×W×H） |
|
整机净重 Net Weight |
820KG |
|
毛重 Gross Weight |
890KG |
|
外包装箱尺寸 Overall Dimension |
2500×800×1780mm（L×W×H） |
|
噪音 Noise |
<75分贝 <75dB |
